| AC A (50/60Hz) |
40/400mA/400A
±1%rdg±5dgt (40/400mA)
±1%rdg±5dgt (0 - 300A)
±2%rdg (300.1 - 399.9A) |
| AC A (WIDE) |
40/400mA/400A
±1%rdg±5dgt [50/60Hz],
±2.5%rdg±10dgt [20Hz - 1kHz] (40/400mA)
±1%rdg±5dgt [50/60Hz],
±2.5%rdg±10dgt [40Hz - 1kHz] (0 - 300A)
±2%rdg [50/60Hz],
±5%rdg [40Hz - 1kHz] (300.1 - 399.9A) |
| Maximum circuit voltage |
600V AC/DC (between line/neutral)
300V AC/DC (against earth) |
| Conductor size |
Ø40mm max. |
| Frequency response |
20Hz - 1kHz [40Hz - 1kHz:400A] |
| Effect of External Stray Magnetic Field |
10mA AC approx. in proximity to a 15mm-dia
conductor carrying 100A AC |
| Applicable standards |
IEC 61010-1 CAT III 300V Pollution Degree 2
IEC 61010-2-032 |
| Response Time |
Approx. 2 seconds |
| Power source |
Two R03 or equivalent (DC1.5V) batteries |
| Dimensions |
185(L) × 81(W) × 32(D)mm |
| Weight |
270g approx. |
| Included Accessories |
9052 (Carrying Case) R03 (1.5V) × 2
Instruction Manual |
| Optional Accessories |
8008 (Multi-Tran)* |
