| AC A |
40.00/400.0/1000A (Auto-ranging)
±1.5%rdg±5dgt (45 - 65Hz)
±2.0%rdg±5dgt (40 - 1kHz) |
| AC V |
4.000/40.00/400.0/600V (Auto-ranging)
±1.8%rdg±7dgt (45 - 65Hz)
±2.3%rdg±8dgt (65 - 500Hz) |
| DC V |
400.0mV/4.000/40.00/400.0/600V (Auto-ranging)
±1.0%rdg±3dgt (400mV range is excluded.) |
| Ω |
400.0Ω/4.000/40.00/400.0kΩ/4.000/40.00MΩ (Auto-ranging)
±2.0%rdg±4dgt (0 - 400kΩ)
±4.0%rdg±4dgt (4MΩ)
±8.0%rdg±4dgt (40MΩ) |
| Continuity buzzer |
buzzer sounds below 50±30Ω |
| Conductor size |
Ø33mm max. |
| Applicable standards |
IEC 61010-1
CAT IV 300V / CAT III 600V Pollution degree 2 (AC A),
CAT III 300V / CAT II 600V Pollution degree 2 (AC/DC V)
IEC 61010-031, IEC 61010-2-032, IEC 61326 (EMC),
EN 50581 (RoHS) |
| Power source |
R03/LR03 (AAA) (1.5V) × 2
*continuous measuring time:
approx. 120 hours (Auto power off: approx. 10 minutes) |
| Dimensions |
190(L) × 68(W) × 20(D)mm |
| Weight |
Approx. 120g (including batteries) |
| Included Accessories |
7107A (Test leads), 9160 (Carrying case), R03 (AAA) × 2,
Instruction Manual |
| Optional Accessories |
8008 (Multi-Tran) |
